EK-Quantum Vector RX 6800/6900 D-RGB - Nickel + Acetal

Product EAN: 3831109833735

In stock!

Pre-Order $159.99

Financing Available

Split the purchase amount of 500 EUR/AUD/USD or more in up to 3 interest-free monthly payments with Splitit.

2 Years Limited
International Warranty

Fast & Free
Technical Support

DHL & UPS Fast Delivery

Payment by Paypal
or Credit card available

Paypal Buyer protection

Made in the EU

Details

EK-Quantum Vector RX 6800/6900 is a 2nd generation Vector GPU water block from the EK® Quantum Line. It is made for graphics cards based on the latest AMD® RDNA2™ architecture. This water block fits most reference PCB designs of the Radeon RX 6800, RX 6800XT, and RX 6900 GPUs.  For a precise compatibility match of this water block, we recommend you refer to the EK Cooling Configurator.

EK-Quantum Vector RX 6800/6900 water block for reference AMD Radeon RX 6800 and 6900 GPUs

EK-Quantum Vector RX 6800/6900 water block is compatible with most reference design Radeon RX 6800, RX 6800XT, and 6900 graphics cards. The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with power stages as well as Inductor chokes to maximize cooling and minimize the chances of coil whine.

These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation.

Fin array is populated by 35 microfins with 0.6mm wide microchannels that provide optimal cooling performance, without unnecessary flow restrictions or clogging hazards.

This water block comes with a single-slot bracket PCI-E expansion for a slick and elegant look. The block is slightly thicker than one slot, to avoid having a steel bridge-plate between the VRM and core parts of the block.

The base of the block is CNC-machined out of high-grade nickel-plated electrolytic copper, while its top is CNC-machined out of durable black POM Acetal. These 2nd generation Vector GPU water blocks also feature acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure.

D-RGB lighting on EK-Quantum Vector RX 6800/6900 D-RGB water block

The aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 6 individually addressable D-RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header.

Backplate for the 6800/6900 water block

EK recommends the purchase of a retention backplate, which improves the overall aesthetics of your graphics cards, and also provides additional passive cooling for the GPU core and backside of the printed circuit board VRM and VRAM sections.

Enclosed:

- EK-Quantum Vector RX 6800/6900  series high-performance water block
- Mounting mechanism with screw-in brass standoffs
- Necessary mounting screws, nuts, and washers
- 2x Nickel plated brass plug G1/4”
- EK-Loop Multi Allen Key (6mm, 8mm, 9mm)
- Thermal pads
Thermal grease EK-TIM Ectotherm (1g)

Technical Specification:

- Dimensions: (LxHxW) - 283x139x16.5mm

Made in Slovenia - Europe!

PLEASE NOTE:

  • This block is made for reference PCB RX 6800/6900 cards.
  • Due to the immense variety of fittings/barbs availablae on the market, we guarantee compatibility only with EK fittings.
  • Factory backplates are not compatible with this water block!
  • Check your toolbox if you are missing this special Hex adapter for some of the screws.
  • This product should NOT be installed with any aluminum Fluid Gaming parts!

Additional Info

Material / Design / Color option Nickel Acetal
Threads G1/4
Chip Manufacturer AMD Radeon
